LT-HBXZ09 Scooter static strength testing machine

Short Description:

This scooter static strength testing machine is designed to precisely evaluate the static load-bearing capacity and deformation characteristics of key structural components (e.g., frame, steering column, folding mechanism). By applying calibrated loads at designated points, it quantifies deflection, stress distribution, and yield limits to provide accurate data for structural design and safety certification.


Product Detail

Product Tags

Product Parameters
1 Plate static load test: The load is cylindrical, with a bottom diameter of 150mm, a height of 300mm, a center of gravity height of 150mm, and weights of 50 ± 0.5kg and 100 ± 1kg respectively. The template can be placed horizontally (pedal static load test) and vertically (direction control column static load test)
2 Static load test of direction control column: 2 sets of load weights, 50 ± 0.5kg and 33 ± 0.5kg respectively
3 Fixed roller fixture adjustable from 0-20cm
4 The rest meet the requirements of relevant items in standards such as GB6675.12-2014 and BS EN 14619-2019



standard
1 GB6675.12-2014
2 BS EN 14619-2019
