Sanitary Ware Dimensional Inspection Bench

Product Advantages

• Granite Datum, Not Marble – A true granite surface plate holds flatness without deflection or corrosion, giving a datum that stays valid through years of production-floor use.
• Two-Plane Checking – The horizontal and vertical granite plates work as a pair, so squareness, height deviation and deformation are read directly instead of calculated indirectly.
• ≤0.5 mm Verified Flatness – Flatness and squareness are both held to ≤ 0.5 mm, matching the tolerance needs of dimensional checks called out in GB 6952 and ASME A112.19.2.
• D65 Lighting for Colour Checks – Daylight-balanced illumination makes glaze colour difference and surface defects judgeable by different operators with consistent results.
• Central Slot for Trapway Work – The slotted station allows drainage and fixture insertion, so ball passage and outlet checks can be performed on the same bench as dimensions.
• Rigid Aluminum Frame – The profile frame keeps the plate stable at a 600 mm working height and can be levelled on uneven factory floors.
