Smart Toilet IPX3 IPX4 Waterproof Test Machine

Short Description:

The Smart Toilet IPX3 IPX4 Waterproof Test Machine is designed to evaluate the water resistance performance of smart toilets and intelligent toilet products according to specified IPX3 and IPX4 testing requirements.

The equipment uses a motorized oscillating tube spray system to simulate water exposure from different directions. The spray flow rate can be automatically adjusted, while the water supply pressure can be controlled from 0–0.8 MPa.

The oscillating tube has a radius of 800 mm and supports multiple swing angles, including 120° and 300°, allowing different water spray conditions to be simulated. The touchscreen control system enables users to set the spray flow rate and test duration from 1–9,999 seconds.

The Smart Toilet Waterproof Tester is suitable for smart toilet manufacturers, sanitary ware manufacturers, quality inspection laboratories, and testing institutions requiring IPX waterproof performance evaluation.

ASK FOR FREE QUOTE

Product Detail

Product Tags

Product parameters
Application	Smart Toilet IPX3 / IPX4 Waterproof Testing
Power Supply	Single-phase AC 220 V, reliable grounding
Working Air Pressure	External supply, 0.3–0.6 MPa
Water Supply Pressure	0–0.8 MPa, static pressure
Maximum Power	3 kW
Control System	Touchscreen
Spray Flow Rate	0.07 L/min per nozzle
Spray Method	Oscillating Tube Spray
Oscillating Tube Radius	R800 mm
Tube Diameter	Inner Ø18 mm / Outer Ø22 mm
Swing Angle	120° total / 300° total
Nozzle Arrangement	Nozzles distributed on 90° arcs on both vertical sides
Nozzle Center Spacing	50 mm
Nozzle Inner Diameter	0.4 mm
Test Platform Load Capacity	≤100 kg
Flow Control	Programmable automatic spray flow adjustment

Applicable Standards
GB/T 34549-2024, Clause 5.16 — Waterproofing of Complete Unit
JG/T 285-2010, Clause 6.2 — Waterproof Grade
GB/T 4208-2008, Clauses 11.1–11.3 and 14
