Sofa Drop Impact Durability Testing Machine

Short Description:

The Sofa Drop Impact Durability Testing Machine is designed to evaluate the impact resistance and structural durability of sofas and other upholstered furniture during handling, transportation, and accidental drops.

The machine simulates impact conditions by pneumatically lifting and releasing the test specimen from a preset height. It supports both single-side drop testing and whole-product drop testing, allowing manufacturers to evaluate different impact conditions.

The lifting and drop height can be adjusted according to the test requirements, with a maximum drop height of 1,000 mm. The PLC-controlled system and touchscreen interface allow users to set the test cycles and operate the equipment conveniently.

The Sofa Drop Impact Tester helps manufacturers identify potential structural damage and improve product design and packaging solutions to reduce transportation-related losses.

ASK FOR FREE QUOTE

Product Detail

Product Tags

Product parameters
Cylinder Stroke Limit	800 mm
Test Cycles	0–999,999 cycles, programmable
Cylinder Diameter	50 mm
Lifting / Drop Height	0–1,000 mm
Drop Method	Pneumatic lifting + electromagnetic release
Lifting Method	Pneumatic
Test Modes	Single-side drop / Whole-product drop
Control System	PLC
Operation Interface	Touchscreen
Air Supply	1.0 MPa (10.2 kgf/cm²)
Power Supply	1-phase, 220 V, 50 Hz
Maximum Specimen Size	Approx. 2,500 × 1,300 mm
Base Plate Size	Approx. 3,500 × 1,500 mm, including movable section
