LT-JJ29-A Computerized National Standard Mattress Surface Durability Testing Machine (Rolling + Height Measurement)

Short Description:

This Computerized National Standard Mattress Surface Durability Testing Machine (Rolling + Height Measurement) evaluates the surface durability and dimensional stability of mattresses by simulating the repetitive rolling motion of a sleeping person. A rolling load module moves back and forth across the mattress surface at a set frequency, testing its resistance to long-term cyclic loading. The system also automatically measures mattress height, providing comprehensive data to assess product quality and lifespan for innerspring, foam, and fiber mattresses in compliance with national mechanical testing standards.

ASK FOR FREE QUOTE

Product Detail

Product Tags

Product parameters
1	Control mode	Computer control
2	Pavement durability test device	(1) Mechanical device capable of driving the roller to move relatively horizontally on the surface of the mattress: the rotational moment of inertia of the roller is (0.5±0.05) kg /m ², the loading frequency should be (16±2) times /min, the static load is (1400±7) N, and the test times are greater than 30,000 times. (2) Roller: Elliptical, with an external dimension tolerance of ±2mm. The surface should be hard, smooth, free of scratches and other surface defects. The length is (1000±2)mm, and the friction coefficient is between (0.2 and 0.5). Roller chamfer: R30. The maximum diameter of the roller: 300±1mm. (3) Motor: Panasonic servo motor from Japan; (4) Test stroke: 250mm on each side of the centerline of the mattress. (5) The accuracy of the force measurement device shall not be less than 1%, the accuracy of the dimensional device shall not be less than 1mm, and the position deviation of the loading block shall be ±5mm.
3	Height measurement device	(1)Height measurement accuracy: ±0.5mm; (2) Height measurement pad: The measurement surface is a flat and smooth rigid cylinder. (3) Measuring pad diameter: 100mm, chamfer R10; (4) Force application speed of the spacer block: 100±20mm/min; (5) Vertical downward force: Apply a force of 4N. At this time, the distance between the lower surface of the circular pad and the flat plate is the height of the mattress surface. Measure the height: After conducting 100 durability tests and 29,900 durability tests on the initial mattress surface, measure the height of the mattress surface respectively. Height measurement system: By setting the force value through software and applying force vertically downward at a fixed speed, it is directly connected to the PLC touch screen.
4	Appearance	Baked paint treatment
5	Test countertop material	Stainless steel
6	Height of the test bench from the ground	180mm
7	Maximum test sample range	2400mm×2400mm×440mm
8	Dimensions	332024002280mm (length * width * height)
9	Test speed	90mm/min; 100mm/min
10	Power supply and power	AC2201V 50HZ single-phase approximately 2KW
11	Weight	Approximately 2.3 tons
