Two-Zone Thermal Shock Test Chamber

Short Description:

The Two-Zone Thermal Shock Test Chamber is designed to evaluate the ability of materials, components, and finished products to withstand sudden changes between extremely high and low temperatures. By rapidly transferring test specimens between hot and cold zones, the chamber accelerates thermal expansion and contraction, helping reveal physical damage, material degradation, and potential failures.

The equipment is suitable for testing metals, plastics, rubber, electronic components, and composite materials. It uses separate high- and low-temperature zones to achieve rapid temperature transitions, making it suitable for thermal shock and reliability testing where conventional temperature cycling may take considerably longer.

A PID + SSR microcomputer temperature control system provides stable temperature regulation, while a two-stage compression refrigeration system supports demanding low-temperature conditions.

ASK FOR FREE QUOTE

Product Detail

Product Tags

Product parameters
1	Temperature range	(150 ℃ – F: – 45 ℃; S: ℃); High temperature zone in high temperature zone:+60 ℃~+150 ℃; Low temperature zone in low temperature zone: – 10 ℃~- 65 ℃; ）
2	Heating time (heat storage area)	about 35min for RT~200 ℃
3	Cooling time (cold storage area)	about 85min for RT~- 70 ℃
4	Temperature recovery time/switching time	≤ 5min/≤ 10sec
5	Temperature control accuracy/distribution accuracy	± 0.5 ℃/± 2.0 ℃
6	Internal and external materials	SUS 304 # stainless steel plate mist surface treatment for the whole machine, stainless steel inner box
7	Insulation material	High-temperature resistant high-density vinyl formate foam insulation material
8	System	P.I.D+S.S.R+Microcomputer balanced temperature regulation control system
9	Cooling system	semi-hermetic double-stage compressor (water cooled)/fully hermetic double-stage compressor (air cooled)
10	Safety protection device	no fuse switch, compressor high and low pressure protection switch, refrigerant high pressure protection switch, fault warning system, electronic alarm
11	Fittings	viewing window (special option), two upper and lower adjustable layers, power-on measuring line hole, castor, horizontal support
12	Power supply	AC380V 50HZ/60HZ 3 Φ
13	Controller	Korean “TEMI” South Korea “TEMI” or Japanese “OYO” Brand Optional
14	Compressor	France/s “Tecumseh” Brand

Standard
1	GJB 150.5A-2009 temperature impact test
2	GB/T 2424.13-2002 Temperature impact test
3	GJB 360B-2009 temperature impact test
4	GB/T 2423.2-2008 High Temperature Test Method
5	GB/T 2423.1-2008/IEC 6008-21-2007 Low-temperature test method
6	GB/T 10589-2008 Technical Conditions for Low-temperature Test Chamber
7	GB/T 11158-2008 Technical Specification for High-temperature Test Chamber
