LT-WY103-B1 Thermostatic water nozzle comprehensive performance testing machine

Short Description:

This Thermostatic Water Nozzle Comprehensive Performance Testing Machine is designed to evaluate the key operational characteristics of thermostatic and digitally controlled thermostatic faucets, including temperature stability, flow rate, response time, and safety functions under varying water pressure and temperature conditions.

ASK FOR FREE QUOTE

Product Detail

Product Tags

Product parameters
1	Working voltage	Three-phase AC380V for water pump, heating and cooling, and single-phase AC220V for the rest
2	Working air pressure	External,0.3MPa to 0.6 MPa
3	Power consumption	Up to 32 KW
4	Test product range	constant-temperature faucets, numerically controlled constant-temperature faucets
5	Host computer	Computer
6	Drive unit	Servo motor
7	Flow sensor range	0 to 30L/min
8	Flow sensor accuracy	1% accuracy
9	The temperature sensor range at the water outlet	0 to 100℃
10	Accuracy of the temperature sensor at the water outlet	±0.5℃
11	External materials	Aluminum profile frame + aluminum-plastic sealing plate
12	Overall dimensions	Length 4800 * Width 1200* Height 1800 (Unit: mm)

Standard
1	QB 2806-2017 10.7.2 Sealing Performance Test
2	QB 2806-2017 10.7.4 Outlet water Temperature stability
3	QB 2806-2017 10.7.5 Security
4	QB 2806-2017 10.7.6 Maximum Outlet Water Temperature test
5	GB/T 24293-2009 7.4.7 Stability of Outlet Water Temperature
6	GB/T 24293-2009 7.4.8 Test of outlet water temperature, outlet water volume and Maximum outlet water temperature when cold water supply is lost
7	GB/T 24293-2009 7.4.9 Initial Temperature Setting
8	QB/T 4000-2010 7.9.8 Outlet water Temperature stability
9	QB/T 4000-2010 7.9.9 Safety Test
