Water Spout Life Testing Machine

Short Description:

This machine is mainly used for durability life test of ordinary water spouts and intelligent water spouts. Modular fixtures support flexible combination, improving equipment utilization and testing efficiency. The control system consists of computer, PLC, water pump, servo motor, air cylinder and supporting professional test software.

ASK FOR FREE QUOTE

Product Detail

Product Tags

Product parameters
1	Working voltage	Three-phase AC380V for water pump, heating and cooling, and single-phase AC220V for the rest
2	Working air pressure	External,0.3 to 0.6MPa
3	Power consumption	Up to 15KW
4	Host computer	Computer
5	Test medium	Cold water: External connection; Hot water: Room temperature water to 90℃
6	Test Station	(Optional)
7	Test product range	1. Single-handle dual-control water nozzle; 2. Single-handle single-control faucet 3. Double-handle double-control faucet 4. Smart faucet;
8	External materials	Aluminum profile frame + aluminum-plastic sealing plate
9	Drive unit	Servo + cylinder
10	Angle range and accuracy	Range 0 to 270°, accuracy: 0.2°
11	Flowmeter	0-30L/min
12	Torque sensor	0-10 N.m
13	Water pump	It can provide 0.02 to 1.0Mpa
14	Overall machine size	Depending on the number of workstations
