General Bathroom Hardware Life Cycle Testing Machine
| 1 | Working voltage | Three-phase AC380V for water pump, heating and cooling, and single-phase AC220V for the rest |
| 2 | Working air pressure | External,0.3 to 0.6MPa |
| 3 | Power consumption | Up to 15KW |
| 4 | Upper computer | PLC (Computer) |
| 5 | Test medium | Cold water: External connection; Hot water: Normal temperature water to 90℃ (adjustable and controllable) |
| 6 | Test station | Optional |
| 7 | Test product range | Single-handle double-control faucet, double-handle double-control faucet, smart faucet, shower head, right-angle valve, flushing device |
| 8 | External materials | Aluminum profile frame + aluminum-plastic sealing plate |
| 9 | Drive unit | Servo + cylinder |
| 10 | Angle range and accuracy | Range 0 to 270°, accuracy: 0.2° |
| 11 | Flowmeter | 0-30L/min |
| 12 | Torque sensor | 0-10NM |
| 13 | Pressure sensor | 0-1.6MPa, 0.5 grade |
| 14 | Water pump | It can provide static pressure ranging from 0.05 to 1.0MPa |
| 15 | Overall machine size | Depending on the number of workstations |
| 1 | GB 18145-2014 8.6.9.1 Faucet Switch Life Test | |
| 2 | GB 18145-2014 8.6.9.2 Switching Switch Life Test | |
| 3 | GB 18145-2014 8.6.9.3 Rotating Outlet Pipe Life Test | |
| 4 | GB 18145-2014 8.6.9.4 Life Test of Extractable Faucets | |
| 5 | QB/T 1334-2013 8.10.1 Service Life of Delayed Self-closing Faucets | |
| 6 | QB/T 1334-2013 8.10.2 Service Life of Induction Faucets | |
| 7 | QB/T 1334-2013 8.10.3 Other faucets | |
| 8 | QB/T 1334-2013 8.10.4 Faucet Conversion switch Service life | |
| 9 | QB/T 1334-2013 8.10.5 Service Life of Rotary Outlet Pipe | |
| 10 | CJ/T 194-2014 8.17.1 Faucet and Shower Life | |
| 11 | GB/T23447-2009 6.7 Test for Thermal fatigue resistance | |
| 12 | GB/T23447-2009 6.12 Shower Head Function Conversion Life Test | |
| 13 | GB/T23447-2009 6.14 Test for Swing Performance of Spherical Connections | |
| 14 | JC/T 932-2013 6.9 Life Test | |
| 15 | GB/T 26712-2011 5.13 Life Testing | |
| 16 | GB26730-2011 6.16 Durability Test | |
| 17 | ASME A112.18.1-2018/CSA B125.1-18 5.6.1.2 Valves or controls | |
| 18 | ASME A112.18.1-2018/CSA B125.1-18 5.6.1.3 Swing spouts | |
| 19 | ASME A112.18.1-2018/CSA B125.1-18 5.6.1.4 Shower heads.body sprays,and hand-held shower assemblies | |
| 20 | ASME A112.18.1-2018/CSA B125.1-18 5.6.1.5 Diverters | |
| 21 | ASME A112.18.1-2018/CSA B125.1-18 5.6.3.1 Mixing valves | |
| 22 | ASME A112.18.1-2018/CSA B125.1-18 5.6.3.2 Metering and self-closing faucets | |
| 23 | ASME A112.18.1-2018/CSA B125.1-18 5.6.3.3 Other devices | |
| 24 | ASME A112.18.1-2018/CSA B125.1-18 5.6.3.4 Swing spouts | |
| 25 |
|
|
