LT-WY211-A1 Spray Test chamber

Short Description:

This spray test chamber is designed to evaluate the water resistance of electronic sanitary ware products, including smart toilets, whirlpool baths, and digitally controlled faucets, by simulating water splashes from various angles to ensure compliance with the IPX4 protection rating standard.

ASK FOR FREE QUOTE

Product Detail

Product Tags

Product parameters
1	Working voltage	Single-phase AC220V, with reliable grounding.
2	Working air pressure	External,0.3MPa to 0.6 MPa
3	Power consumption	Up to 6KW
4	Host compute	Touch screen (optional computer)
5	Spray volume	0.07L/min/ nozzle
6	Spray method	Swing pipe flushing mode
7	Swing pipe size	The swing pipe is a 180° semi-circular swing pipe Radius: R200mm, pipe diameter inside the swing pipe is 16mm; R600mm, the inner diameter of the swing pipe is 25mm; R1400mm, the diameter of the swing pipe is 32mm; The swing pipes are interchangeable
8	Swing Angle	Swing 150° to both sides from the center point, totaling 300°. The Angle within this range can be set
9	Spray piping cycle	Adjustable from 5 to 12 seconds
10	Nozzle arrangement	The nozzles are distributed on 90° arcs on both vertical sides, with a center distance of 50mm between each nozzle
11	Nozzle inner diameter	0.4mm
12	Load capacity of the test bench	Nozzle arrangement
13	Water supply system	Water tank water supply, tap water replenishment
14	Overall dimensions	Length 3000* Width 2500* height 2100 (Unit: mm)

Standard
1	GB4706.53-2008 Special Requirements for Toilets 15.1.1 It may be necessary to conduct tests on the inner side of the seat using the nozzle described in 14.2.4b) of GB4208-2008.
2	GB4706.1-2005 Safety of household and similar electrical appliances – Part 1: General Requirements 15 Moisture resistance
3	The waterproof grade test of JG/T285-2010 toilet bifacial apparatus 7.3 shall be conducted in accordance with Clause 14.2.4 of GB4208-2008
4	GB/T 24293-2009 Numerical Control Constant Temperature Faucet 7.7 Electrical Enclosure Protection Grade test
5	QB 2585-2007 Electrical Safety of Jet Massage Bathtubs (GB 4706.73-2004 IPX4,IPX5)
6	The overall waterproof grade of the smart toilet is tested in accordance with Clause 14.2.4 of GB4208-2008
