LT-LLZ02-AS electronic desktop tensile testing machine

Short Description:

This electronic desktop tensile testing machine is a compact, benchtop unit for conducting precise tension, compression, and flexure tests on small to medium-sized specimens. It features a digital control system with a high-precision load cell and a servo-driven mechanism for accurate speed and displacement control. The machine automatically measures key mechanical properties—including tensile strength, yield strength, elongation, and elastic modulus—and is suitable for testing metals, plastics, composites, and other materials in compliance with standards such as ASTM and ISO, making it ideal for quality control, education, and R&D laboratories.

ASK FOR FREE QUOTE

Product Detail

Product Tags

Product parameters
1	Capacity options	1kg, 2kg, 3kg, 5kg, 10kg, 20kg, 50kg
2	Unit Switching	The four units of kg, g, Lb and N can be converted freely
3	Load decomposition degree	1/1000
4	Load accuracy	±1%
5	Maximum stroke	300mm
6	Test speed	Either 10 to 250 mm/min or 50 to 500 mm/min can be selected
7	Display	It can show the test value, the maximum value or the rupture value
8	Motor	40W
9	Volume	Approximately 4305300530mm
10	Weight	Approximately 35 kilograms
11	Power supply	1∮,AC220V,1A
