LT-WY400-A1 Comprehensive Performance Test Bench for Shower Enclosures

Short Description:

This Comprehensive Performance Test Bench for Shower Enclosures is a dual-function testing system designed to evaluate both the water-tightness (sealing performance) and the load-bearing capacity (structural strength) of shower cabins or enclosures. It allows the majority of required tests to be performed with a single installation of the product, enabling efficient and integrated quality validation in compliance with relevant industry standards.

ASK FOR FREE QUOTE

Product Detail

Product Tags

Product parameters
1	Working voltage	Three-phase AC380V for the water pump, and single-phase AC220V for the rest, with reliable grounding.
2	Working air pressure	External,0.3MPa to 0.6 MPa
3	Power consumption	Up to 5KW
4	Upper computer	PLC+ touch screen
5	Sensor	500KG
6	Sandbags	one 15Kg and one 50Kg respectively
7	Adjustment range	Up and down: 0 to 0.5 meters, left and right: 0 to 1.0 meters
8	Test space	3740mm in length * 1660mm in width * 3500mm in height or customized as per customer requirements.
9	Material of shape	Aluminum profile + aluminum-plastic sealing plate
10	Overall dimensions	Length 4000mm; Width: 2000mm; Height: 2800 mm or customized according to customer requirements

Standard
1	QB2584-2007 Shower Room 5.4.4 Drainage Performance Test
2	QB2584-2007 Shower Enclosure 5.4.5 Sealing Performance Test
3	QB2584-2007 Determination of the limit dimensions of the door opening width for Shower enclosures 5.4.6
4	QB2584-2007 Minimum spacing of door handles for shower enclosures 5.4.7
5	QB2584-2007 Shower Enclosure 5.5.2 Determination of Enclosure Structure Strength
6	GB/T 13095-2008 Test for Moisture and Heat Resistance of Integral Bathrooms 7.6
7	GB/T 13095-2008 Integral Bathrooms 7.8.1 Sandbag impact Test
8	BS EN 14428-2015 5.6 Stability
9	BS EN 14428-2015 5.7 Water retention
