Single Wing Drop Testing Machine

Short Description:

The Single Wing Drop Testing Machine is designed to evaluate the damage resistance and impact strength of packaged products during transportation and handling. By dropping a test package from a specified height onto a rigid impact surface, the machine simulates accidental drops that may occur during loading, unloading, handling, and transportation.

The equipment supports face, edge, and corner drop testing, allowing packages to be evaluated from different impact orientations. The drop height can be adjusted from 300 to 1500 mm, with a maximum specimen weight of 80 kg.

An electric transmission system provides convenient height adjustment, while the LED digital display allows operators to accurately monitor the selected drop height. The machine is suitable for packaging development, transportation simulation, quality control, and laboratory testing.

ASK FOR FREE QUOTE

Product Detail

Product Tags

Product parameters
1	Drop height (mm)	Adjustable from 300 to 1500
2	Maximum weight of the specimen kg	0-80Kg
3	Base plate thickness	10mm (solid iron plate)
4	Maximum specimen size (mm)	800 x 800 x 1000
5	Impact panel size mm	1700 x 1200
6	Arm size (mm)	16025010
7	Drop height error	±10mm
8	Dimensions of the test bench (mm)	approximately 1700 x 1200 x 2300
9	Height display	LED instrument digital display
10	Test method	All-round drop on the face, corners and edges
11	Transmission method	Electric transmission
12	Parallel error of the impact panel	≤1 degree
13	The angular error between the falling surface and the horizontal during the falling process	≤1 degree
14	Power Supply	380V V, AC380V 50HZ
15	Power	1.5KW
16	Net weight kg	approximately 550kg
