Office Chair Armrest Fatigue Testing Machine

Short Description:

The Office Chair Armrest Fatigue Testing Machine is designed to evaluate the durability and fatigue resistance of office chair armrests under repeated lateral loading. The test applies cyclic force to the armrest at an angle of 10° from the vertical line, simulating repeated side pressure that may occur during normal use.

The chair is securely fixed to the test platform, while the loading fixture can be adjusted according to the chair structure and testing position. With its adjustable cylinder force direction, the machine can also be used for testing other furniture components such as chair seats and footrests, making it a versatile testing solution for furniture manufacturers and laboratories.

A precision pressure regulation system ensures stable loading force, while the PLC and touchscreen control system provides real-time display of test speed, frequency, cycle count, and force.

ASK FOR FREE QUOTE

Product Detail

Product Tags

Product parameters
1	Adjustable distance from cylinder pivot to loading pad	500~900mm
2	Cylinder specification	50mm diameter, output force meets the strength and precision requirements for armrest testing
3	Loading pad	Width: 100mm, applies force to the armrest at a 10° inclination angle
4	Pressure control system	Precision pressure regulating valve ensures stable and reliable cylinder output force, with digital display of force value
5	Control system	PLC control + touch screen with real-time display of speed, frequency, cycles and force value
6	Power supply	220VAC 1.0A
7	Air source requirements	Air pressure ≥0.5MPa; Flow rate ≥800L/min; Air source must be filtered and dried
8	Overall machine dimension (L×W×H)	approximately 130011001820mm(length * width * height)
9	Weight	Approximately 320kg
10	Standard accessories	1 set of armrest loading fixture; 2 pcs of cylinder adapters; 2 pcs of chair fixing pressure plates
11	Load cell capacity	200kg
