LT-HBXZ02 Scooter dynamic strength testing machine

Short Description:

This scooter dynamic strength testing machine is designed for comprehensive dynamic strength and durability evaluation of scooters in accordance with EN 13843 and other international standards. It precisely simulates impacts, loads, and fatigue conditions during riding to ensure product safety meets the most stringent certification requirements.

ASK FOR FREE QUOTE

Product Detail

Product Tags

Product parameters
1	Drum diameter: 700mm ± 10mm
2	Drum speed: 0.5m/s ± 5%
3	Load: 20-100KG adjustable
4	Testing time: 1min-99h
5	Control system: Adopting PLC touch screen controller
6	Measurement accuracy: speed ± 1km/h, load ± 1kg, time error accuracy of 0.1s
7	Power source: Motor control system equipped with fixtures: 90 ° fixtures, 70 ° fixtures
8	Obstacles: Steel, trapezoidal installation, with dimensions in accordance with standards such as EN13843:2009, EN 13613:2009, EN 14619:2019, etc
9	Weight addition: Scooter durability kit
10	PLC automatic control, with all test data observed on the touch screen; Accurately record and test the running time and cumulative number of times in real-time; Adopting touch screen control, all operations can be intuitively operated on the touch screen. The use of dedicated control software can achieve fully automatic control, automatic measurement, and other functions of multi-channel closed-loop control to complete the experiment
11	The detection frequency can be set, and after the detection is completed, the equipment will automatically shut down and give an alarm prompt
12	Equipped with stop/power off memory and breakpoint detection shutdown function; After a sudden power outage, if you call again, the device can automatically save data and run on the battery according to the parameters set before the power outage, without the need for manual startup to set parameters
13	Shutdown mode: Upon reaching the number of test cycles, the machine will automatically shut down and sound an alarm if the equipment is damaged or deformed excessively
14	The equipment has a fault self diagnosis system, which automatically diagnoses and displays fault codes when faults occur, facilitating inspection and troubleshooting
15	Set up 4 workstations according to EN13843:2009, EN 13613:2009, and EN 14619:2019 standards
16	The rest meet the requirements of relevant items in standards such as EN13843:2009, EN 13613:2009, and EN 14619:2019
