The Xenon Lamp Aging Test Chamber Featured Image

The Xenon Lamp Aging Test Chamber

Short Description:

The Xenon Lamp Aging Test Chamber adopts xenon arc lamp simulating full solar spectrum to reproduce destructive light waves existing in various environments, providing environmental simulation and accelerated aging tests for scientific research, product development and quality control.
It conducts aging tests by exposing material specimens to xenon arc illumination and thermal radiation, to evaluate the light and weather resistance performance of materials under high-temperature light sources. Widely applied in automotive, coating, rubber, plastic, pigment, adhesive, textile, aerospace, shipbuilding, electronics, packaging and other industries.
This xenon weathering test chamber supports selection of new materials, modification of existing materials or evaluation of durability changes after material composition adjustment. It can perfectly simulate changes of materials exposed to sunlight under diverse environmental conditions.

Product Detail

Product Tags

Product parameters
1 Temperature range RT+10 ℃ – 70 ℃
2 Test blackboard temperature 40 ℃ – 100 ℃, adjustable
3 Humidity range 30% – 98% RH
4 Humidity uniformity ≤ ± 3 ℃
5 Temperature accuracy ≤ ± 0.1 ℃
6 Humidity accuracy ≤ ± 1 ℃ RH
7 Temperature and humidity sensor PT100 Ω/MV platinum resistance
8 Rotary table/rotating speed Φ 600mm; 1～3r/min
9 Lamp tube Source 1 water-cooled lamp tube (Teelong)
10 Service life of lamp tube 1000-1200 hours
11 Lamp power 4.5KW/6.5KW
12 Distance from arc center to sample 250-300MM effective exposure area 640cm²
13 Light cycle time 0～999H, M, S continuously adjustable
14 Rainfall time 0～9999min continuous rainfall adjustable
15 Rainfall period 1~min interval (interruption) rainfall adjustable
16 Spraying period 18min/102min or 12min/48min (spraying time/no-spraying time)
17 Rain water pressure 0.12-0.15Mpa
18 Spray nozzle aperture Φ 0.8mm
19 Standard sample size 75mm * 150mm
20 Spectral wavelength 290-800nm
21 Xenon lamp radiation intensity 290-800nm wave band 500-1120w/m2
22 Filter Type Simulate light passing through glass window, sun filter, UV filter, either
23 Material used (1) Outer box material: high-quality carbon steel plate, phosphatized electrostatic spraying treatment/SUS304 stainless steel
(2) Inner box material: SUS316 high-quality stainless steel smooth plate
(3) Sample holder material: SUS316 high-quality stainless steel strip
(4) Door frame: high and low temperature aging resistant silicone rubber door sealing strip
24 Service conditions voltage: 380:10% V, 50 ± 1% HZ, power: 15KW three-phase five-wire system
25 Environmental conditions temperature: 5 ℃ ～ 30 ℃ Relative humidity ≤ 85% RH Air pressure: 86kpa ～ 106kpa
26 Safety device leakage, short circuit, overtemperature, water shortage, motor overheating, overcurrent protection





Standard
1 GB/T16422.3
2 15422.1 AATCCM16
3 ASTM-D4459
4 GBT2423.24
